$227M Americana by Loews Arlington Hotel Will Require 7 Low Voltage Systems for 2029 Opening

$227 million Americana by Loews Hotels — Arlington requires seven low voltage systems across a 22-story, 507-room hospitality mega-project, creating an estimated $12 million low voltage opportunity in the booming North Texas Entertainment District market.

Project Overview

A $227,338,653 vertical construction permit has been filed for "Loews Arlington III" — the working name for what Loews Hotels & Co will brand as Americana by Loews Hotels — Arlington. According to permit records filed with the City of Arlington, the project is a Type I-A new construction hotel with 22 stories above grade (23 occupiable levels) and 507 guest rooms, packaged with full MEP scope and a long list of deferred submittals including cold-formed metal framing, electronic traction elevators, glazed aluminum framing, operable partitions, and vented kitchen hoods.

The project replaces the existing Sheraton Arlington Hotel, which ceased operations in February 2026 with demolition scheduled to start in June. Loews has stated total investment will exceed $500 million across the full multi-phase development, with the $227M permit reflecting the active vertical construction scope. Opening is targeted for late 2028 or early 2029, ahead of LA28 — and just as importantly, deeply tied to the year-round event calendar at AT&T Stadium and Globe Life Field next door.

Project	Americana by Loews Hotels — Arlington (Loews Arlington III)
Location	Arlington Entertainment District, Arlington, TX
Permit Value	$227,338,653 (vertical construction)
Total Project Investment	$500M+ (full development)
Building Profile	Type I-A, 22 stories above grade, 23 occupiable levels, 507 guest rooms, 39 suites, 83,000+ SF meeting/event space
Project Type	Hotel — Mega-Project
Status	Active — Sheraton demolition June 2026; opening late 2028 / early 2029
LV Score	8/10
Source	Arlington TX Issued Permits

Key Players

This is a high-visibility public-private hospitality mega-project with deeply public ownership, partnership, and operating disclosures.

Role	Company	Details
Owner / Operator	Loews Hotels & Co	Loews' third Arlington property, joining Live! by Loews Arlington and the existing Loews Arlington Hotel. Anchor brand expanding the Entertainment District.
Development Partner	The Cordish Companies	Master developer of Texas Live! and the broader Entertainment District. Long-running hospitality and mixed-use partner with the Texas Rangers.
Sports / Civic Anchor	Texas Rangers	Co-developer of Texas Live!. The Entertainment District anchors Globe Life Field (Rangers) and AT&T Stadium (Cowboys).
Predecessor	Sheraton Arlington (demolished)	The site's prior occupant. Final operations ceased in February 2026; demolition planned for June 2026 to clear the parcel.

Low Voltage Systems Breakdown

Hotel mega-projects are some of the most LV-intensive commercial buildings in construction. Branded hospitality at this scale layers public-area AV, guestroom IPTV/WiFi, banquet AV, F&B point-of-sale, executive-floor security, and code-compliant life safety on top of base building infrastructure.

System	Category	Scope Description	Complexity
Structured Cabling	Data / Voice	Building-wide Cat6A and OS2 fiber backbone serving 507 keys, 39 suites, public areas, F&B outlets, and the 83,000 SF meeting/event package. Distributed IDFs on every floor with redundant pathways.	Very High
Wi-Fi Infrastructure	Wireless / Guest Experience	High-density Wi-Fi 6E or Wi-Fi 7 access point coverage in every guestroom, ballroom, breakout space, lobby, and pool deck. Captive portal, brand-standard SSID, and Loews loyalty integration.	Very High
Access Control	Security / Hospitality	Mobile key and RFID guestroom locks integrated with the property management system, plus card readers at staff entries, BOH corridors, executive floors, F&B BOH, and parking. Loews enterprise security federation.	High
CCTV	Security	Multi-hundred-camera IP video surveillance covering perimeter, lobbies, F&B, ballroom, BOH, parking, and pool. Long retention windows for hospitality liability and integration with broader Entertainment District security ops.	High
Fire Alarm	Life Safety	Voice-evacuation addressable system covering all 23 occupiable levels including high-rise stair pressurization, smoke control, and mass notification. NFPA 72/101 compliance plus Arlington Fire Department coordination.	Very High
AV Systems	Communications / Banquet	Ballroom rigging and AV-over-IP backbone, breakout-room displays, lobby and elevator digital signage, in-room IPTV, fitness/pool zone audio. Broadcast tie-in for stadium-event watch parties.	Very High
POS Systems	F&B / Retail	Point-of-sale infrastructure for restaurants, bars, lobby café, banquet outlets, and gift shop. Fiber to BOH, redundant network, EMV-compliant terminals, integration with property management and corporate F&B.	High

Estimated Low Voltage Value

Industry benchmarks for full-service branded hotels at this scale place low voltage and technology scope at roughly 5–7% of total construction value, weighted toward the high end because of guestroom Wi-Fi density, branded AV, and meeting-space technology. Applied at 5.5% to the $227M permit value, the estimated low voltage contract value lands near $12.5 million.

Permit Value (vertical construction)	$227,338,653
Estimated LV Percentage	5.5% (full-service hotel)
System Count Multiplier	1.0x (7 systems, AV/Wi-Fi heavy)
Estimated LV Contract Value	~$12,500,000

Realistically, structured cabling + Wi-Fi infrastructure together claim the largest share — likely $4–5M between them given 507 guestroom drops, fiber backbone, and high-density wireless. AV systems for the 83,000 SF meeting-space package run another $3–4M. Fire alarm voice-evac for a 22-story high-rise is a $1.5–2M scope on its own. Access control, CCTV, and POS round out the package. Across the full $500M+ Loews development, the all-in LV scope is meaningfully larger when FF&E technology and operator-supplied systems are included.

Skills and Certifications Required

Branded hospitality at this scale is unforgiving on credentialing. Every major LV system on this project will require certified design, certified install, and Loews brand-standard commissioning before opening day.

System	Key Certifications	Critical Skills
Structured Cabling / Wi-Fi	BICSI RCDD, BICSI INSTC/INSTF, manufacturer cert (Panduit, CommScope, Aruba/Cisco)	Multi-floor backbone design, guestroom Cat6A pathway, Wi-Fi 6E/7 RF design, captive portal, Loews IT brand standards
Fire Alarm	NICET Fire Alarm Level III+, Texas State License (FAPS or FAT)	High-rise voice-evac, smoke control, NFPA 72/101 compliance, AFD coordination, mass notification
AV Systems	AVIXA CTS-D, CTS-I, manufacturer cert (Crestron, Extron, Dante, QSC, Biamp)	Ballroom rigging, AV-over-IP backbone, in-room IPTV, broadcast tie-in, central control programming
Access Control	Manufacturer cert (HID, ASSA ABLOY VingCard, Salto), PSP	RFID/BLE mobile key integration with PMS, hospitality lifecycle, BOH zoning, Loews enterprise federation
CCTV	Manufacturer cert (Avigilon, Axis, Genetec, Milestone)	High-density IP camera deployment, hospitality VMS, long retention, federation with district security
POS	Manufacturer cert (Oracle Simphony, Toast, Agilysys), PCI / EMV compliance	Multi-outlet POS architecture, PMS integration, redundant networking, EMV compliance

Texas requires a state Low Voltage Technician license (LVT) for low voltage work and a Fire Alarm Planning Superintendent (FAPS) registration for fire alarm systems, both administered through the Texas Department of Licensing & Regulation. The project will be a multi-prime, multi-trade undertaking with bonded capacity, prevailing wage compliance, and Loews brand-standard documentation requirements. Out-of-state integrators with hospitality bench may be invited as specialty subs but local Texas presence and stadium-district experience will be heavily weighted.

Market Signal

The Arlington Entertainment District is in the middle of a once-in-a-generation buildout. Loews now operates three properties on the same parcel cluster — joining Live! by Loews Arlington and the existing Loews Arlington Hotel — and the new Americana adds 507 keys plus 83,000 SF of meeting space anchored between AT&T Stadium and Globe Life Field. The economic-impact projection from Loews and the City of Arlington is $3.1 billion over the next 30 years.

For North Texas low voltage contractors, the implication is concrete: this is one $227M permit inside a multi-billion-dollar Entertainment District buildout that has been adding hospitality, mixed-use, and entertainment scope continuously since Texas Live! opened. Bidding and executing well on the Americana scope positions a contractor to be on the short list for the next ten years of district-adjacent work — including future Cordish-led mixed-use and any LV refresh on the existing Loews properties.

The broader signal: branded hospitality at scale is back. After the pandemic-era hospitality lull, mega-hotel projects are returning to construction calendars, especially in markets that combine sports, entertainment, and convention demand. Arlington has all three. The $12M+ LV scope on this single project is the kind of opportunity that defines a regional integrator's decade.
